The 20×2 Monochrome Character LCD Module is a 20×2 blue backlight LCD. This LCD module currently has 3 different variations. Their same attributes are:
Similarly, different customers have different needs, this 20×2 Monochrome Character LCD Module has different attributes:
Welcome to custom more others 20×2 Monochrome Character LCD Module!
| Drawing | Model number | Classify | IC | Outline dimension(mm) | Viewing area | Pin number | Backlight |
|
HSM2002A | 20×2 | AIP31066 | 116×37×13.2mm | 85×18.6mm | 16 | Side BL |
|
|
HSM2002E | 20×2 | AIP31066 | 146×43×12.6mm | 123×23mm | 16 | Side BL |
|
|
HSM2002B | 20×2 | AIP31066 | 180×40×13.8mm | 149×23mm | 16 | Side BL |
LCD types: TN / STN / FSTN / DFSTN / HTN and more LCD types.
Character count: 8×2, 16×2, 20×4, 24×2, 40×2, and more. — tell us how many characters you need.
Transmissive / Reflective / Transflective: Besides transmissive (for indoor use), we offer reflective and transflective options for outdoor devices like electric meters.
Wide temperature range: Standard character LCDs run −20°C to 70°C. We also provide extended versions from −40°C to 90°C.
Viewing angle: Standard is 6/12 o’clock viewing. We can also customize to 3/9 o’clock if your application needs it.
We provide comprehensive technical support to ensure your LCD projects run smoothly from start to finish.
1. Datasheets: Receive complete datasheets for every product free of charge. Our team is ready to explain any details and answer your questions in clear, easy-to-understand language.
2. Sample Code: Each COB Character LCD module comes with example code, helping you quickly understand how it works and how to integrate it into your project.
3. After-Sales Service: Get one-on-one assistance from experienced engineers with over 10 years in the LCD industry. They will help you troubleshoot and guide you through development challenges.
4. Legacy Product Replication: If you have an older product that’s no longer in production, we can create a compatible replacement that matches your original design.
Lowest MOQ = 100 units each product.
We’ll choose the most cost-effective solution to you.
We keep products in supply for at least 5+ years.
One-by-one service from experienced staff and engineers with over 14 years in the field.
Samples in 7 days, mass production in 30 days, and even faster for in-stock products.
HUA XIAN JING accelerates client innovation through free design prototype LCD module and backward-compatible upgrades for obsolete displays, backed by round-the-clock engineering support.
Over the years, rich experience in LCD module generation has led us to accumulate 10,000+ standard LCD modules in our standard library, download our catalog to select the LCD module that best suits your needs!
