16×4 Monochrome Character LCD Module
16×4 Monochrome Character LCD Module is a 16×4 red LCD. This LCD module currently has 2 different variations. Their same attributes are:
- Driver IC: AIP31066;
- Pin Number: 16 Pins.
Similarly, different customers have different needs, this 16×4 Monochrome Character LCD Module has different attributes:
- Outline Dimension: 87×60×11mm / 87×60×13mm;
- View Area: 62×25.5mm / 62×26mm;
- Backlight: Red / Blue / Yellow Green / Grey.
Welcome to custom more others 16×4 Monochrome Character LCD Module!
Overview
| Drawing | Model number | Classify | IC | Outline dimension(mm) | Viewing area | Pin number | Backlight |
 |
HSM1604A | 16×4 | AIP31066 | 87×60×11mm | 62×25.5mm | 16 | Side BL |
|
HSM1604B | 16×4 | AIP31066 | 87×60×13mm | 62×26mm | 16 | Side BL |
|
HSM1604I | 16×4 | ST7066U-0B+ST7065 | 70.6x61x9mm | 60x32mm | 16 | Side BL |
Source from 24 years Brand Manufacturer
- 100+ R&D team members
- 3 production plants
- Daily output value: 300,000 pieces
- Multiple environmental certifications
Consult with an expert
+86 13632586591
